MINI SKID STEER AUGER DRIVES
Premier Attachments produces 3 Mini Skid Steer Auger Drives specifically designed for the hydraulics GPM and PSI of this popular machine. These Medium-Duty Auger Drives are cost-effective, powerful, and designed to maximize the hydraulics of the various machinery available.
- We offer mounting brackets that include the Universal Mini Skid Steer mount as well as the Bobcat MT mount
- A full range swivel that allows the auger to hang plumb to the ground at any angle
- Output shafts available in 2" hexagon and 2-9/16" round
SPECS
| Model |
Max Auger Diam. |
Min Hyd: GPM/RPM |
Max Hyd: GPM/RPM |
Min Hyd: PSI/Torque |
Max Hyd: PSI/Torque |
Output |
Warranty |
| MS11PD | 24" | 7/45 |
11/71 |
2500/1274 |
3500/1783 |
2" Hex & 2-9/16" Rnd |
3 Years |
| MS14PD | 30" |
12/50 | 17/71 |
2500/1825 |
3500/2555 |
2" Hex & 2-9/16" Rnd | 3 Years |
| MS18PD | 36" |
15/50 |
20/67 |
2500/2290 |
3500/3206 |
2" Hex & 2-9/16" Rnd |
BIG DAVE
When choosing a auger drive first, decide on the style or "duty" of the drive you want. If you are only using occasionally the standard unit will work fine in most cases. Second, choose the shaft type. The most common now days is the 2" hex shaft. Third, match up the hydraulics of your machine with the hydraulic categories on the website. Finally you can compare specs between brands but that can become overwhelming and confusing. A quick way to determine performance is looking at the max bit specification.
